APPENDIX
ENGINEERING DRAWINGS TECHNICAL CONTENT REQUIREMENTS
SCOPE
10.
10.1 Scope. This appendix covers the technical content requirements chat
should be included on drawings when required by the contract or order. This
appendix is mandatory only when data item description DI-DRPR-80651 is cited on
the DD Form 1423
20.
APPLICABLE DOCUMENTS
20.1 Government documents.
20.1:1 Specifications. standards, and handbooks. The following specifi-
cations, standards, and handbooks form a part of this document to the extent
specified herein. Unless otherwise specified, the issues of these documents are
those listed in the issue of the Department of Defense Index of Specifications and
Standards (DODISS) and supplement thereto, cited in the solicitation (see 6.2).
SPECIFICATION
MILITARY
MIL-T-31000 - Technical Data Packages, General Specification for.
(Unless otherwise indicated, copies of federal and military specifications,
standards, and handbooks are available from the Standardization Documents Order
Desk, BLDG 4D, 700 Robbins Avenue, Philadelphia, PA 19111-5094. )
30.
DRAWINGS
30 1 Drawing content, In addition to the drawing content required by
MIL-T-31000, drawings shall contain the following:
(a)
overall outline dimensions of the complete actuator.
(b)
Dimensional location of ports
Port sizes and connections.
(c)
Internal porting and flow paths
(d)
Port identification markings (example C-1, C-2, and so forth).
(e)
Dimensional location and size of mounting holes.
(f)
Torque values for bolting or fastening devices
(g)
Calculated dry weight of actuator
(h)
Calculated fluid volume of actuator.
(i)
Center of gravity when wet weight (fluid filled) of actuator
())
exceeds 100 pounds
Transverse and longitudinal cross-sectional views showing actuator
(k)
action and internal working parts
Detailed sections of views considered necessary to amplify the
working parts of the actuator
